Pleiades-1A/1B

The Pleiades satellites work as a pair in phased orbits, and can perform daily revisits to any point on Earth. They provide highly detailed imagery at 50cm panchromatic resolution as well as 2m multispectral resolution.

For defence, intelligence and security use

50cm data over 20km swath

Data delivery in record time

Daily revisit

Consult Our Experts

Download Summary

Pléiades-1A/1B Specs

Launch Information

Launch Date: December 17, 2011
Site: Guiana Space Centre, Kourou, French Guiana

Orbit

Altitude: 695 km
Type: Sun synchronous
Inclination: 98.2°
Period:98.79min

Mass

1,000 kg

Sensor Bands

4-band multispectral (blue, green, red and NIR)

Sensor Resolution

At nadir – 70-cm panchromatic & 2.8-m multispectral

Dynamic Range

12-bits per pixel

Swath Width

20km

Focal Plane

5 panchromatic array assemblies – 6,000 pixels per array, 13 µm pixel size

5 multispectral array assemblies – 1,500 pixels per array, 52 µm pixel size

Retargeting Agility

Slew > 3° per second within < 2 seconds

Revisit Frequency (at 40°N Latitude)

1 day (43° off-nadir)
4 days (30° off-nadir)
5 days (20° off-nadir)
13 days (5° off-nadir)

Max Contiguous Area Collected in a Single Pass (30° off-nadir)

Mono, large area, 20° off-nadir – 120 km x 65 km (6 strips wide)
Mono, large area, 30° off-nadir – 140 km x 105 km (6 strips wide)

Geolocation
Accuracy (CE90)

< 10-m CE90 (global average, dependent on terrain)

Capacity

Daily constellation capacity: 1,000,000 sq.km.
